Innovo Water Heater

Innovo Water Heater

AO Smith logo - BFC Cyclone

The Innovo IR water heater range consists of nine high efficiency condensing fully room-sealed gas water heaters. Automatic gas/air premix deliver efficient operation with a maximum temperature set point of 85°C and a NOx output of less than 37 mg/kWh, ensuring compliance with the strictest European guidelines.

ENQUIRE NOW
Technical Specifications
innovo condensing boiler Adveco
Installation drawing unvented innovo Adveco
Previous
Next

Features & Key Technologies

  • Outputs from 11.7 to 31.3 kW
  • Efficiencies up to 98% gross
  • Water capacities from 160 – 380 litres
  • NOX emissions from 22 – 37 mg/kWh
  • Automatic gas/air premix burning system
  • Suitable for moderate DHW demand systems in hard water areas
ENQUIRE NOW

Options

Available with single and three phase electric elements a load profile between XL and XXL can be attained depending on the Innovo appliance. Construction of the heat exchangers limits scaling effect, and the appliance includes low-maintenance inert anodes.

Low standby losses are achieved through Innovo’s complete insulation. This helps deliver ErP efficiency varies between 90 and 94%.

Innovo is easy to operate and manage with external an on-/off-switch, and voltage-free contact for general fault indication to BMS

Innovo supports an number of options including: T&P valve with stainless-steel spring set to 95°C and a maximum water pressure of 7 bar; analogue temperature gauge (0-120°C); and power anodes

Ideal Uses & Applications

  1. Moderate DHW demand systems
  2. Suitable for hard water areas
  3. Flexible flue option and flexible anodes supports installation almost anywhere, including confined areas

Additional Information

  1. All components are accessible through the front cover for easy maintenance
  2. Suitable for use with low-cost plastic flue material
  3. Suited for natural gas and butane/propane
ENQUIRE NOW

Technical Specifications & Downloads

PDF icon. Innovo Instruction Manual

PDF icon. Innovo Specification Sheet

PDF icon. Innovo Flue gas discharge material

PDF icon. Innovo160 CAD dimensions drawings

PDF icon. Innovo200 CAD dimensions drawings

PDF icon. Innovo380 CAD dimensions drawings



PDF icon. Innovo Declaration of Conformity

PDF icon. IR 12-160 Energy Label

PDF icon. IR 12-200 Energy Label

PDF icon. IR 20-160 Energy Label

PDF icon. IR 20-200 Energy Label

PDF icon. IR 24-245 Energy Label

PDF icon. IR 24-285 Energy Label

PDF icon. IR 32-245 Energy Label

PDF icon. IR 32-285 Energy Label

PDF icon. IR 32-380 Energy Label

PDF icon. Innovo ERP Efficiency Declaration

PDF icon. Innovo GAR Certificate


View table as a PDF (14kb)

Innovo Load profile Energy efficiency class Energy efficiency
12-160 XL A 92%
20-160 XL A 92%
12-200 XL A 94%
20-200 XL A 91%
24-245 XL A 92%
32-245 XL A 92%
24-285 XL A 91%
32-285 XL A 90%
32-380 XL A 90%
